The new Cebora SYNSTAR 270 T SRS edition is a three-phase multi-process inverter power source for MIG – TIG – MMA welding, particularly versatile and suitable for various applications.

› MIG SHORT process (double current level)
› PULSE MIG and DOUBLE PULSE MIG processes
› SRS MIG process (Spatter Reduction System) to thoroughly achieve spatters-free welds with reduced
heat input
› System calibration procedure to adjust all welding parameters and process variables (possibility
of setting the features of the welding torch) – only available with SRS MIG
› LIFT TIG process (easy polarity reverse)
› PULSE TIG process (optional)
› Synergic curves for wires of Ø 0.6 / 0.8 / 0.9 / 1.0 / 1.2 mm, including stainless steel pulse
synergic programs optimized for small thickness welds
› LCD touch-screen display to view and adjust the key functions:
Type of process, type of wire or gas and arc length, current and thickness, voltage and wire speed
› Dust filter to protect the power source against iron powders
› USB and RS232 ports to easily update the software
› CEBORA 4-roller-wire feed unit (Ø 30 mm)

SYNSTAR 270 T SRS edition can be equipped with several different types of torches:
› CEBORA MIG Push-Pull torch, air-cooled, – cable length 4 m (Art. 2003), self-limited to 200 A
› CEBORA MIG torch, air-cooled, 280 A 60% – cable length 3,5 m (Art. 1242)
› CEBORA MIG torch, water-cooled, 380 A 60% – cable length 3,5 m (Art. 1241)
› BINZEL TIG “ABITIG 450 W” torch, – cable length 4 m (Art. 1256) combined with extension lead (Art. 2068)

› On request, the cooling unit (Art. 1681) is also available

Power sources characterized by low electrical input (PFC)
Compliant with EN 61000-3-12 standard

SRS (Spatter Reduction System

Short circuit welding process that offers several advantages:

› No spatters in welding
› Low heat input in welding
› Suitable for thin thicknesses and for reduced distortions
› Excellent root pass also on root sides
› Easy achievement of the first pass on especially open edges
› Precise and stable arc with excellent control of the welding pool
› Optimal weld bead, even aesthetically

Art.	564
	MIG – TIG	MMA
	400 V 50/60 Hz +15% / -20%		Three phase input
	16 A		Fuse rating (slow blow)
	9,3 kVA 20% 6,9 kVA 60% 5,3 kVA 100%	9,5 kVA 20% 7,3 kVA 60% 5,4 kVA 100%	Input power
	10 ÷ 270 A	10 ÷ 250 A	Min.-max. current that can be obtained in welding
	270 A 20% 220 A 60% 180 A 100%	250 A 20% 200 A 60% 160 A 100%	Duty Cycle (10 min.40°C) According to IEC 60974-1
	Electronic		Stepless regulation
	0,6/0,8/0,9/1,0/1,2 Fe 0,8/0,9/1,0/1,2 Al 0,8/0,9/1,0/1,2 Inox 0,8/0,9/1,0 Cu-Si 3%		Standard supplied synergic programs
	Ø 300 mm/15 kg		Max. wire spool size
	IP23S		Protection class
	68 kg		Weight
	510x1020x865 mm		Dimensions (WxLxH)
